Overview of BSMJ series cylindrical low-voltage power capacitors

BSMJ series self-healing environment-friendly capacitors are produced in full accordance with the international standard IEC60831-1:2002 "Self-healing parallel capacitors for AC power systems with nominal voltage of 1kV and below". It is used to increase power factor, reduce reactive power loss and improve voltage quality. This type of products in Europe and the United States and other countries for the mainstream products.

Main features:

■ The design is more reasonable: considering the capacitance capacity is different, the current carrying capacity is different, the design will be the shell diameter ≥86mm, the use of type B

Terminal, the current carrying area is larger, no heat, but also installed overtemperature protection device.

■ Safe use: This product is made of cylindrical aluminum stretched shell, this structure has strong protection function, eliminate the explosion, leakage hazards, safety and environmental protection.

■ The new high-quality metallized polypropylene film for capacitors is used as the insulating medium, which has small specific characteristics, small volume, low temperature rise, excellent electrical properties, long service life of capacitors, and greatly improves the capacity of a single compensation cabinet.

■ Wider application environment: with unique design and process, the product can adapt to higher ambient temperature and system voltage fluctuations.

■ Easy installation and use: the bottom of the M12/M16 stud installation, so that users more convenient installation and adjustment.

■ The BKMJ cylindrical capacitor can realize the modular design of reactive power compensation cabinet, reduce the unit cost of equipment and make maintenance more convenient.

■ When BKMJ is used, all of them are connected in parallel, and the whole is broken into pieces, that is, the damage of one capacitor does not affect the use of other groups, effectively reducing equipment maintenance costs.
